SIZES – Stage dimensions are 3m x 2m (W x H) and is 0.6m from the ground

Opening between truss is 2.5m and 2.3m (W x H)

RIGGING – This stage, built in 2024, is twin axle trailer mounted – Truss is Global Truss F24 Series quad truss and can be used to hang additional equipment from using appropriate truss clamps or cable ties. A black mesh backdrop is attached at the rear to  allow the wind to pass trough it. Printed mesh backdrops can be supplied where event branding is required and attatched to the roof structure and handrails. Further branding options are available, please enquire. A bespoke tarpaulin roof cover is used to give some protection from the sun or rain. Black skirt is provided to hide wheels at front. Stage steps at 200mm and 400mm height are provided for easier access by performers.

CREW – Comes with experienced crew to deliver, instal and operate the Dinky Stage.

SOUND SYSTEM – Suitable for audiences of up to 200 – (Bigger systems are available)
RCF ART910 Powered speakers (2) (2100w peak power each)
Passive 8″ Stage Monitors (For performer fold back)
Allen & Heath CQ18 sound desk (With iPad remote mixing)
1 Radio Mic (Hand held - other vocal options available)
Shure Beta 58/SM58/SM57/Vintage/Instrument Mics (As required)
Passive and active DI Boxes (As Required)

LIGHTING - Controlled from side of stage

2  x IP65 LED RGB Battens backlight

4 x LED RGB Pars for side lighting

2 x IP65 Rated floods for face light

Lighting can be supplemented according to the style of your event. This can include moving light, audience lighting and venue enhancement lighting

CONTROL POINT – Stage sound and lighting can be controlled from within our Pop-up 1.8m x 1.8m at the side of the stage. Mixing is done primarily with an iPad

POWER –The Dinky Stage runs from a single 13a power supply (We supply cables) The unit can be sited up to 50m from a fixed supply, or we can provide a small generator. (At extra cost incl. fuel)


A tow vehicle is required to be on site, for security of unused aquipment and for weaher protection and welfare of our crew

EXTRAS – Additional things like bigger sound systems, weatherproof lighting, generator, extra crew, branding banners, longer cable runs and lecterns can be added to your package to suit your requirements.

Please contact us if you require any further technical information

We look forward to hearing from you
